What is Ollama, and How to Deploy It in an Enterprise Data Stack?

Running Your First Model - Getting Started

Step 1: Check Available Models

# Via CLI (inside the pod)
kubectl exec -n hyperplane-ollama <pod-name> -- ollama list


Step 2: Pull a Model

If no models are listed, pull one:

# Via CLI
kubectl exec -n hyperplane-ollama <pod-name> -- ollama pull llama3.1


Step 3: Run a Simple Prompt

# Via CLI
kubectl exec -n hyperplane-ollama <pod-name> -- ollama run llama3.1 "What is machine learning?"


Essential Commands

‍‍
OpenAI-Compatible Endpoint

Ollama supports the OpenAI API format at /v1/chat/completions:

from openai import OpenAI

client = OpenAI(
   base_url="<http://localhost:11434/v1>",
   api_key="not-needed"
)

response = client.chat.completions.create(
   model="llama3.1",
   messages=[{"role": "user", "content": "Hello, how are you?"}]
)
print(response.choices[0].message.content)


Other Useful Endpoints

| Endpoint | Method | Purpose |
|----------|--------|---------|
| `/api/tags` | GET | List all downloaded models |
| `/api/pull` | POST | Download a model |
| `/api/version` | GET | Get Ollama version |
| `/api/show` | POST | Show model details |



Using LangChain

from langchain_community.llms import Ollama

llm = Ollama(base_url="<http://localhost:11434>", model="llama3.1")
result = llm.invoke("What is the capital of France?")
print(result)


Model Selection Guide

This section is for customers using Ollama as a managed component inside Shakudo. Start from the Shakudo platform instead of installing or exposing Ollama manually.

1. Access the component in Shakudo

• Sign in to your Shakudo workspace with your organization-approved account.
• Open the workspace or environment where this component is enabled.
• Go to the Applications or component catalog area and select Ollama.
• If you cannot see the component, ask your workspace administrator to confirm that it is enabled for your role and environment.

2. Open the component UI

• Use the Shakudo-provided Open, Launch, or Access action for Ollama.
• Let Shakudo handle authentication, networking, and workspace routing. Avoid using internal service URLs unless your administrator explicitly provides them.
• Confirm that the component opens in the expected workspace before creating or changing resources.

3. Complete a first safe use case

Open the Ollama endpoint or UI exposed through Shakudo and run a small model test, such as a short completion or embedding request, using the model that your workspace administrator has enabled.

• Use a small non-production example first, especially when testing credentials, scans, model calls, or data connections.
• Name the test clearly so other workspace users can recognize it as a first-run validation.

4. Monitor and validate the result

• Check the component UI for run status, logs, traces, scan results, job history, or project activity, depending on the component.
• Return to Shakudo if you need platform-level status, access control changes, or administrator support.
• Record any errors, missing permissions, or unexpected results before retrying with production workloads.

5. Next steps

• Review the use cases, administration, and troubleshooting pages in this knowledge base for deeper examples.
• For production usage, follow your team’s Shakudo workspace policies for credentials, data access, resource limits, and approvals.

Ollama Administration & Best Practices

Model Management

Pulling Models

Models can be pulled manually or automatically:

Manual pull (recommended for production):

kubectl exec -n hyperplane-ollama <pod-name> -- ollama pull llama3.1


Auto-pull via Helm values:

ollama:
 models:
   pull:
     - llama3.1
     - mistral


Tip: In production, prefer manual pulls. Auto-pull runs on every pod start, which slows startup and can cause failures if the registry is unreachable.

Listing, Inspecting, and Removing Models

# List all downloaded models
ollama list

# Show model details (size, format, parameters)
ollama show llama3.1

# Remove unused models to free PVC space
ollama rm phi3:mini


Custom Models with Modelfile

FROM llama3.1
PARAMETER temperature 0.3
PARAMETER num_predict 512
SYSTEM You are a helpful technical assistant. Be concise and accurate.
ollama create my-assistant -f Modelfile
ollama run my-assistant "What is Kubernetes?"


Model Storage and PVC Sizing

| Models to Store | Recommended PVC Size |
|----------------|---------------------|
| 1–2 small models (7B–8B) | 30 GB |
| 3–5 mixed models | 100 GB |
| Large models (34B–70B) | 200 GB |


GPU Configuration

Enabling GPU

ollama:
 gpu:
   type: nvidia

resources:
 limits:
   nvidia.com/gpu: 1

tolerations:
 - key: nvidia.com/gpu
   operator: Exists
   effect: NoSchedule


GPU Comparison

| GPU | VRAM | Good For | Approx. Speed (8B model) |
|-----|------|----------|--------------------------|
| T4 | 16 GB | Dev/test, small models | ~30 tokens/sec |
| L4 | 24 GB | Production, moderate load | ~40 tokens/sec |
| A10G | 24 GB | Production, good throughput | ~50 tokens/sec |
| A100 | 80 GB | Large models, heavy load | ~80+ tokens/sec |


Monitoring GPU

nvidia-smi  # Inside pod or on node


DRA (Dynamic Resource Allocation): The Helm chart supports it, but leave disabled unless your cluster explicitly supports it.

Networking & Security

Service Exposure

| Method | Use Case |
|--------|----------|
| **ClusterIP + VirtualService** | Default — expose via Istio with SSO |
| **ClusterIP + port-forward** | Development and debugging |
| **NodePort** | Direct access without Istio (not recommended for production) |


Authentication

• SSO via Keycloak — Handled by the platform's OAuth2 proxy
• API key — Ollama doesn't require API keys by default; authentication is handled at the gateway level
• Network policies — Restrict access to the Ollama service from specific namespaces

Istio Sidecar

The Istio sidecar is required for external routing. Verify injection:

kubectl get pods -n hyperplane-ollama -o jsonpath='{.items[*].spec.containers[*].name}'
# Should show "ollama" and "istio-proxy"


If the sidecar is missing, add to values.yaml:

podLabels:
 sidecar.istio.io/inject: "true"


Performance Tuning

Key Environment Variables

| Variable | Default | Purpose |
|----------|---------|---------|
| `OLLAMA_NUM_PARALLEL` | 1 | Number of parallel request sequences |
| `OLLAMA_MAX_LOADED_MODELS` | 1 | Max models loaded in memory simultaneously |
| `OLLAMA_KEEP_ALIVE` | 5m | How long to keep models loaded after last request |
| `OLLAMA_MAX_VRAM` | 0 (auto) | Max VRAM to use (0 = all available) |


Tuning Recommendations

• Increase OLLAMA_NUM_PARALLEL if you need to handle concurrent requests (requires more VRAM)
• Increase OLLAMA_KEEP_ALIVE (e.g., 24h) to avoid cold-start delays on frequently used models
• Set OLLAMA_MAX_VRAM if you need to reserve GPU memory for other workloads
• Use smaller models for latency-sensitive applications

Monitoring & Observability

Health Check

curl <http://localhost:11434/api/version>


Key Metrics to Monitor

• GPU utilization — nvidia-smi or DCGM metrics
• Memory usage — Pod memory consumption vs limits
• Request latency — Time to first token and total response time
• Error rate — Failed inference requests

Log Review

kubectl logs -n hyperplane-ollama <pod-name> --tail=100
kubectl logs -n hyperplane-ollama <pod-name> | grep -i error


Upgrades & Maintenance

Upgrade Process

1. Backup values, model list, and deployment manifest
2. Dry run: helm upgrade --dry-run --debug
3. Execute: helm upgrade --wait --timeout 15m
4. Validate: check pod, version, models, inference

Key Points

• Recreate strategy = brief downtime — Plan accordingly
• Keep models.clean: false — Never enable cleanup during upgrades
• Check VirtualService — May disappear after upgrades (known issue)
• Rollback available — helm rollback ollama -n hyperplane-ollama

Scaling Considerations

• Vertical scaling — Move to a larger GPU (T4 → A10G → A100) for better performance
• Horizontal scaling — Deploy multiple Ollama instances behind a load balancer
• Model sharding — 70B+ models can be split across multiple GPUs
• Dedicated GPU nodes — Isolate Ollama on its own node pool to avoid resource contention

Ollama Troubleshooting & FAQ

Common Issues

Model Not Loading

Problem: Model fails to load or "model not found" error.

What to check:

• Run ollama list — is the model listed?
• Check PVC disk space — df -h inside the pod
• Verify the model name spelling (e.g., llama3.1 not llama-3.1)
• Check pod logs for loading errors

Fix:

• Pull the model again: ollama pull llama3.1
• Free disk space by removing unused models: ollama rm <unused-model>
• Use the exact model name from ollama list

Slow Performance / Inference

Problem: Model responses are very slow (seconds per token).

What to check:

• Is GPU being used? Run nvidia-smi to check
• Which model size are you running? (70B on CPU will be extremely slow)
• How many concurrent requests? Check OLLAMA_NUM_PARALLEL
• Check pod memory usage — may be swapping to disk

Fix:

• Enable GPU if available (see GPU Configuration in Admin guide)
• Use a smaller model (switch from 70B to 8B)
• Reduce OLLAMA_NUM_PARALLEL to 1
• Increase pod memory limits
• Set OLLAMA_KEEP_ALIVE to keep models loaded (avoids cold start)

Out of Memory Errors

Problem: Pod is OOMKilled or returns "out of memory" error.

What to check:

• Pod resource limits vs model size
• How many models are loaded simultaneously
• GPU VRAM utilization with nvidia-smi

Fix:

• Use a smaller model (8B instead of 70B)
• Increase memory/VRAM limits in values.yaml
• Set OLLAMA_MAX_LOADED_MODELS: 1 to limit concurrent model loading
• Set OLLAMA_MAX_VRAM to prevent Ollama from using all GPU memory
• Reduce OLLAMA_NUM_PARALLEL

API Not Responding / 404 Error

Problem: curl to Ollama API returns connection refused, 404, or white screen.

What to check:

• Is the pod running? kubectl get pods -n hyperplane-ollama
• Does the service exist? kubectl get svc -n hyperplane-ollama
• Does the VirtualService exist? kubectl get virtualservice -n hyperplane-ollama
• Is the port correct? (Should be 11434, not 8080)

Fix:

• If pod is not running: check logs with kubectl logs
• If VirtualService is missing: this is a known issue after upgrades — create it manually:

apiVersion: networking.istio.io/v1
kind: VirtualService
metadata:
 name: ollama-vs
 namespace: hyperplane-ollama
spec:
 gateways:
 - hyperplane-istio/ingress-gateway
 hosts:
 - ollama.<your-domain>
 http:
 - match:
   - uri:
       prefix: /
   route:
   - destination:
       host: ollama
       port:
         number: 11434


• If port is wrong: ensure VirtualService routes to port 11434

GPU Not Being Used

Problem: Ollama runs on CPU even though GPU nodes are available.

What to check:

• Run nvidia-smi on the GPU node — is it functional?
